Product parameters
| parameter | Details | unit |
| Display size (diagonal) | 1.85 | inch |
| LCD type | a-Si TFT | - |
| display mode | IPS / Transmissive / Normally Black | - |
| resolution | 360RGB x 360 | - |
| display area | 45.68(H) x 45.68(V) | Mother |
| Module appearance | 47.99(H) x 49.86(V) × 2.12(T) | Mother |
| Display color | 262K | - |
| interface | MIPI/QSPI/8BIT/SRGB | - |
| Driver IC | 77916 | - |
| TP window | 46.08(H) x 46.08(V) | Mother |
| TP shape | 55(H) x 55.8(V) x 0.7(T) | Mother |
| brightness | 550 | cd/m² |
| Viewing direction | All | - |
| Contrast | 1200:1 | - |
| Color gamut | 70 | % |
| PPI image point density | 200 | - |
| window effect | All black | - |
| cover surface effect | No AF/AG | - |
| working temperature | -20~60 | ℃ |
| storage temperature | -30~70 | ℃ |
| weight | TBD | - |
| connector | OK-F302-39115 | - |
| Touch firmware version | V02 | - |
