Product parameters
| parameter | Details | unit |
| Display size (diagonal) | 5.0 | inch |
| LCD type | α-Si TFT | - |
| display mode | IPS / Transmissive / Normally Black | - |
| resolution | 720RGBx1280 | - |
| display area | 62.1(H) × 110.4(V) | Mother |
| Module appearance | 66.40(H) × 120.05(V) × 1.70(T) | Mother |
| Display color | 16.7M | - |
| interface | MIPI | - |
| Driver IC | IL19881 | - |
| TP window | 62.6(H) × 110.9(V) | Mother |
| TP shape | 68.6(H) × 149.9(V) × 1.225(T) | Mother |
| brightness | 450 | cd/m² |
| Viewing direction | All | - |
| Contrast | 800:1 | - |
| Color gamut | 70 | % |
| PPI image point density | 294 | - |
| window effect | All black | - |
| cover surface effect | Plated AF | - |
| working temperature | -20~70 | ℃ |
| storage temperature | -30~80 | ℃ |
| weight | TBD | - |
