Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 4.0 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 400RGBx960 | - |
| Active Area display area | 39.18(H)×94.032(V) | Mother |
| Module Outline module appearance | 42.9(H)×102.08(V)×1.58(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | - |
| InterfaceInterface | 16bit RGB/MIPI | - |
| Driver ICDriver IC | ST7701S | - |
| TP Viewing Area TP Window | none | Mother |
| TP Outline(assembly)TP outline | none | Mother |
| View DirectionView direction | FREE | Best image |
| Contrast ratioContrast ratio | 1500:1 | |
| Color gamut color gamut | 65% | |
| PPI image point density | 260 | |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | None A F /AG | - |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
