Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 4.0 | inch |
| LCD typeLCD display type | α-Si TFT | |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | |
| Resolution | 480RGBx480 | |
| Active Area display area | 71.86(H)×70.18(V) | Mother |
| Module Outline module appearance | 74.66(H)×76.54(V)×2.1(T) | Mother |
| Luminance on surfaceBrightness | 350 | |
| Display ColorsDisplay Colors | 16.7M | |
| InterfaceInterface | 18bit RGB | |
| Driver ICDriver IC | ST7102 | - |
| TP Viewing Area TP Window | 72.46(H)×70.78(V) | Mother |
| TPOutline(assembly)TP outline | 84(H)×84(V)×0.7(T) | Mother |
| View DirectionView direction | ALL | Best image |
| Contrast ratioContrast ratio | 1200:1 | |
| Color gamut color gamut | 70% | |
| PPI image point density | 173 | |
| Window effect Window effect | All black | |
| Cover plate surface effect cover plate surface effect | No AF/AG | |
| Operating TemperatureOperating temperature | -20～70 | C |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
