Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 2.46 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 440RGBx642 | - |
| Active Area display area | 33.924(H)×49.5(V) | Mother |
| Module Outline module appearance | 36.324(H)×55.44(V)×1.56(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | - |
| InterfaceInterface | MIPI | - |
| Driver ICDriver IC | ST7701 | - |
| TP Viewing Area TP Window | 34.324(H)×49.9(V) | Mother |
| TPOutline(assembly)TP outline | 40.995(H)×63.20(V)×0.7(T) | Mother |
| TPIC | CST3530 | - |
| Luminance on surfaceBrightness | 900 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 1200:1 | |
| Color gamut color gamut | 72% | |
| PPI image point density | 329 | - |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | Plated AF | - |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
