Product parameters
| parameter | Details | unit |
| Display Size(Diagonal) Display Size(Diagonal) | 2.19 | inch |
| LCD type LCD type | α-Si TFT | - |
| Display Mode display mode | IPS / Transmissive / Normally Black | - |
| Resolution | 240RGB x 400 | - |
| Active Area display area | 31.68(H)×52.8(V) | Mother |
| Module Outline Module outline | 34.82(H) ×59.81(V)×1.89(T) | Mother |
| Display Colors display colors | 16.7M | - |
| Interface interface | MIPI+8bit | - |
| Driver IC Driver IC | ST7701S | - |
| TP Viewing Area TP Window | none | Mother |
| TP Outline(assembly) TP outline | none | Mother |
| Luminance on surface luminance | 450 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 1000:01:00 | |
| Color gamut color gamut | 65% | |
| PPI image point density | 192 | - |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | No AF/AG | - |
| Operating TemperatureOperating temperature | -20～70 | ºC |
| Storage TemperatureStorage temperature | -30～80 | ºC |
| Weight | TBD | indivual |
