For action camerasMiniaturization, lightweight and special-shapedDesign trends, providing full-size, special-shaped glass customization services, breaking the standard size restrictions.

1. Size range: Focus on 1.0-3.0-inch mainstream action camera screens, supportNon-standard aspect ratio, round, oval, with cutout (camera/sensor)Customized special-shaped glass;
2. Thickness customization: ultra-thin 0.55mm-1.1mm optional, taking into account thinness and strength, suitable for ultra-thin body designs of 5-8mm;
3. Structure customization: supportNarrow bezel (narrowest 0.3mm), no bezel, 2.5D/3D curved surfaceGlass improves screen-to-body ratio and appearance;
4. Precision control: glass size tolerance ±0.05mm, opening position tolerance ±0.1mm, ensuring perfect fit with the fuselage to avoid light leakage and looseness.

The cover serves as the “first line of defense” for action camera screens, focusing onAnti-scratch, anti-glare, impact-resistant, waterproof and anti-fingerprintFour core functions, providing multi-process combination customization.

1. Material customization:
   • Basic model: high-aluminum tempered glass, surface hardness ≥9H, resistant to sand and gravel friction and daily scratches;
   • Upgraded version: Corning Gorilla Glass/Sapphire Glass, impact strength increased by 50%, suitable for high-altitude drops and hard object impact scenarios;
2. Surface process customization:
   • AG anti-glare process: haze 10%-30% optional, eliminates outdoor glare reflections, and improves visibility on cloudy/sunny days by 80%;
   • AF anti-fingerprint technology: hydrophobic and oleophobic, leaving no traces on wet hands, sweat, or oily environments, and smooth touch;
   • AR anti-reflection process: light transmittance ≥90%, reducing screen reflection and improving picture clarity and color reproduction;
   • Explosion-proof process: laminated with explosion-proof film, no sharp fragments after fragmentation, ensuring safety for use in extreme sports;
3. Customized edge craftsmanship: 2.5D/3D arc edge polishing, smooth hand feel, avoiding bumps and scratches, while improving waterproof sealing.

The interior space of the action camera is narrow, vibrations occur frequently, and the cable arrangement can be customized to focus.Miniaturization, shock resistance, flexibility, solving the problems of spatial adaptation and signal stability.

1. Structure customization:
   • Length customization: 5-50mm, any length, adapts to different internal wiring requirements of the fuselage, and avoids redundant winding;
   • Position customization: supports multi-directional cable arrangement such as left exit, right exit, bottom exit, side exit, etc., matching the position of the mainboard interface of the fuselage;
   • Width customization: 0.3-1.0mm ultra-thin cable, saving internal space and adapting to compact design;
2. Performance customization:
   • Material upgrade: Made of high-temperature-resistant and bend-resistant FPC material, with a bending capacity of ≥10,000 times, suitable for high-frequency vibration scenarios such as cycling and skiing;
   • Interface customization: Compatible with eDP, LVDS, MIPI and other mainstream sports camera interfaces, supports gold finger/connector two connection methods, stable plugging and unplugging;
   • Strengthening and reinforcement: Add reinforcing plates to the bends of the cable to increase the bending strength and avoid cable breakage and signal interruption during movement.

For action camerasLow temperature, high humidity, underwater, wear glovesFor special usage scenarios, customized high-stability touch solutions ensure accurate and sensitive operation.

1. Structure customization:
   • Mainstream structure: G+G (glass + glass) structure, high hardness, scratch resistance, long life, suitable for high-intensity outdoor scenes;
   • Thin and light structure: G+F (glass + film) structure, thin and low cost, suitable for entry-level action cameras;
2. Performance customization:
   • Wide temperature touch: -20℃ to +60℃ stable operation, suitable for extreme temperature environments such as snowy mountains and deserts;
   • Wet hand/underwater touch: Optimize the touch sensing algorithm, support precise touch in clean water, sweat, and rain environments, and adapt to underwater shooting scenes;
   • Touch control with gloves: Supports touch operation with thin sports gloves (≤2mm), and parameters can be adjusted without taking off the gloves;
   • High sensitivity and low false touches: touch response time ≤10ms, supports single/multi-point touch, shields vibration and water stain interference, and reduces false touches;
3. Lamination process: Use full lamination/frame lamination process to eliminate the air layer between the screen and the touch layer, reduce reflection, improve picture clarity, and enhance waterproof sealing.
