Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 6.86 | inch |
| LCD typeLCD display type | α-Si TFT | · |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | |
| Resolution | 480RGBx 1280 | |
| Active Area display area | 160.59(H)×60.22(V) | Mother |
| Module Outline module appearance | 181(H)×66.6(V)×7.15(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | |
| InterfaceInterface | MIPI | |
| Driver ICDriver IC | ICN9707 | |
| TP Viewing Area TP Window | none | Mother |
| TPOutline(assembly)TP outline | none | Mother |
| Luminance on surfaceBrightness | 450 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 900:1 | |
| Color gamut color gamut | 55% | |
| PPI image point density | 202 | |
| Window effect Window effect | All black | |
| Cover plate surface effect cover plate surface effect | 无AF/AG | |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
