Product parameters
|
parameter |
Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 3.92 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 480RGBx128 | - |
| Active Area display area | 95.04(H)×25.34(V) | Mother |
| Module Outline module appearance | 102.46(H)×34.4(V)×3.56(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | - |
| InterfaceInterface | 8bit/SPI/DSPI/QSPI | - |
| Driver ICDriver IC | NV3041A | - |
| TP Viewing Area TP Window | / | Mother |
| TP Outline(assembly)TP outline | / | Mother |
| Luminance on surfaceBrightness | 400 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 1200:1 | |
| Color gamut color gamut | 50% | |
| PPI image point density | 128 | - |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | None A F /AG | - |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
