Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 3.5 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 640RGBx480 | - |
| Active Area display area | 70.08(H)×.52.56(V) | Mother |
| Module Outline module appearance | 74.38(H)×62.35(V)×2.31(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | |
| InterfaceInterface | MIPI | - |
| Driver ICDriver IC | ST7703 | - |
| TP Viewing Area TP Window | 70.68(H)×53.16(V) | Mother |
| TPOutline(assembly)TP outline | 77.52(H)×65(V)×1.45(T) | Mother |
| TP structure | G+FF | |
| TPIC | CST3530 | |
| I2C voltage | 3.3V | |
| Luminance on surfaceBrightness | 450 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 1200:1 | |
| Color gamut color gamut | 60% | |
| PPI image point density | 231 | one |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | None A F /AG | |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
