3.2-inch TFT horizontal screen 1024*768

Product parameters

parameter	Details	unit
Display Size(Diagonal)Display size(diagonal)	3.2	inch
LCD typeLCD display type	α-Si TFT	-
Display ModeDisplay Mode	IPS/Transmissive/Normally Black	-
Resolution	1024RGBx768	-
Active Area display area	64.51(H)×48.38(V)	Mother
Module Outline module appearance	69.6(H)×55.7(V)×2.1(T)	Mother
Display ColorsDisplay Colors	16.7M	-
InterfaceInterface	RGB 16bit	-
Driver ICDriver IC	9168	-
TP Viewing Area TP Window		Mother
TPOutline(assembly)TP outline	-	Mother
Luminance on surfaceBrightness	400	cd/m²
View DirectionView direction	All	Best image
Contrast ratioContrast ratio	1200:1
Color gamut color gamut	65%
PPI image point density	403
Window effect Window effect	All black
Cover plate surface effect cover plate surface effect	None A F /AG
Operating TemperatureOperating temperature	-20～70	℃
Storage TemperatureStorage temperature	-30～80	℃
Weight	TBD	indivual
Corresponding connector model	OK-F302-39115
