Product parameters
|
parameter |
Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 2.2 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 640RGBx320 | - |
| Active Area display area | 49.44(H)×25.09(V) | Mother |
| Module Outline module appearance | 51.94(H)×31.39(V)×1.36(T) | Mother |
| Display ColorsDisplay Colors | 16.7M | - |
| InterfaceInterface | MIPI | - |
| Driver ICDriver IC | ILI9881D | - |
| TPViewing Area TPViewing Area | - | Mother |
| TPOutline(assembly)TP outline | Mother | |
| Luminance on surfaceBrightness | 850 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 1000:1 | |
| Color gamut color gamut | 72% | |
| PPI image point density | 328 | - |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | No AF | - |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
