Product parameters
| parameter | Details | unit |
| Display Size(Diagonal)Display size(diagonal) | 1.89 | inch |
| LCD typeLCD display type | α-Si TFT | - |
| Display ModeDisplay Mode | IPS/Transmissive/Normally Black | - |
| Resolution | 320RGBx386 | - |
| Active Area display area | 29.57(H)×35.67(V) | Mother |
| Module Outline module appearance | 31.58(H)×39.32(V)×1.6(T) | Mother |
| Display ColorsDisplay Colors | 262K | - |
| InterfaceInterface | QSPI | - |
| Driver ICDriver IC | GC9B71 | - |
| TP Viewing Area TP Window | 30.07X36.17 | Mother |
| TP Outline(assembly)TP outline | 34.56(H)×45.5(V)×1.3(T) | Mother |
| Luminance on surfaceBrightness | 400 | cd/m² |
| View DirectionView direction | All | Best image |
| Contrast ratioContrast ratio | 800:1 | |
| Color gamut color gamut | 60% | |
| PPI image point density | 274 | |
| Window effect Window effect | All black | - |
| Cover plate surface effect cover plate surface effect | None A F /AG | - |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
