Product parameters
| Features | Details | Unit |
| Display Size(Diagonal) Display Size(Diagonal) | 2.38 | inch |
| Display type | α-Si TFT | - |
| Display ModeDisplay Mode | Transmissive/Normally Black | - |
| Resolution | 240RGBx320 | - |
| Active Area display area | 36.72(H)×48.96(V) | Mother |
| Module Outline module appearance | 40.02(H)×56.95(V)×2.15(T) | Mother |
| Display ColorsDisplay Colors | 262K | |
| InterfaceInterface | QSPI | |
| Driver ICDriver IC | NV3031 | - |
| TPViewing Area TPViewing Area | - | Mother |
| TPOutline(assembly)TP outline | - | Mother |
| Luminance on surfaceBrightness | 150 | cd/m² |
| View DirectionView direction | 8 o'clock direction | Best image |
| Contrast ratio Contrast (Transmittance) | 80:1 | |
| Contrast ratio Contrast (Reflection) | 6:1 | |
| Color gamut color gamut (Transmittance) | 20% | |
| Color gamut color gamut (Reflection) | 7% | |
| PPI image point density | 166 | |
| Window effect Window effect | Semi-reflective and semi-transparent | - |
| Cover plate surface effect cover plate surface effect | No AF/AG | |
| Operating TemperatureOperating temperature | -20～70 | ℃ |
| Storage TemperatureStorage temperature | -30～80 | ℃ |
| Weight | TBD | indivual |
