Product parameters
| parameter | Details | quantity |
| Surface finger resistance Pattern coating resistant grind |
The water drop angle before the experiment is ≥110°, and the water drop angle is ≥100° after the experiment. | 3 pcs |
| Surface finger resistance Pattern coating Uniformity |
surface vapor | 5 pcs |
| Ink adhesion | ≥4B (the shedding area is less than 5%, and the entire frame cannot fall off) | 3 pcs |
| temperature shock | -40℃±2℃/80℃±2℃, 100 cycles, ink adhesion ≥3B | 5 pcs |
| Boiling test | After testing for 30 minutes at 100℃±2℃, recovery for 2h at room temperature, ink adhesion ≥3B | 3 pcs |
| Ink opacity | Black and white ≥5.0, other colors ≥4.5 | 3 pcs |
| DOL/CS/CT | 900≤CS≤1250Mpa, 6.4≤DOL≤8.3um, 110≤DOC≤130um, 110≤CSK≤190Mp a,60≤CT≤105Mpa |
5 pcs |
| 4 point bend | ≥600Mpa | 30 pcs |
| surface pencil hardness |
1000gf,≥7H | 3 pcs |
